5700MSC-IP
IP Network Grand Master Clock & Video Master Clock System
Page - 2 Revision 0.2
The SPG section of the 5700MSC-IP provides six independent timeable reference outputs. These six
sync outputs may be configured to provide independently timed color black (black burst) outputs,
independently timed HDTV tri-level sync outputs, 10MHz outputs, word clock, and various available
pulses.
It is available with a main processing board and optional redundant power supply.
Features:
• Modular 1RU design
• IP Network Grand Master Clock for NTP, PTP-IEEE1588, MASTER PCR, AVB-IEEE802.1AS,
and SMPTE 2059-2
• 2 x 1000BASE-T RJ45 ports
• 2 x 10 GbE ports (SFP’s are not provided and are optional)
• 6 independently timeable sync outputs, 8 with the +AUX option
• 4 optional SDI test generator outputs with the +SDI-TG option (supports SD/HD/3Gbs SDI)
• Optional 10 GbE video test generator support with the +10G-TG option (SFP’s are not included)
• Configurable to run in Boundary Clock mode for larger enterprise scale network designs (with
an upstream 5700MSC-IP Grand Master Clock)
• Can drive and interoperate with the sister product, the modular 7800SRG-IP, which is a PTP
referenced SPG (to generate NTSC and PAL blackburst HD, and other bespoke analog
reference signals.)
• GNSS referenced system capable of receiving GPS and GLONASS satellite constellation
signals – outdoor antenna and 50ft cable provided.
• Optional 100ft, 400ft, 800ft, 1200ft and fiber optic extenders available for GNSS antenna
• All active components are front panel extractable & serviceable
• Optional dual power supply for redundancy (+2PS option)
• Full featured front panel control interface
• Contact closure output for critical warning (+AUX option)
• VistaLINK
®
control for device configuration and status monitoring
• Multi System GNSS referenced designs will be in sync and timed.
• An optional expansion module (+AUX option) provides AES & analog audio test generator, LTC,
DARS, and GPIO functionality.
• An optional automatic changeover unit (5700ACO) provides automatic survivability changeover
for baseband signals (video reference,wordclock, 10Mhz, LTC, DARS, and SDI test generators)
Ordering Options:
• +2PS Redundant power supply
• +SDI-TG 4 outputs, configurable SD/HD/3G SDI test/black generators
• +10G-TG Test generator outputs over 10 GbE ports and 4 SDI outputs,
configurable SD/HD/3G SDI test/black generators (includes +SDI-TG
option)
• +AUX Includes expansion test module which provides AES and analog audio
test generator, DARS, GPIO, and LTC outputs.
SFP Options:
• +SFP10G-TR13-A 1310nm laser, standard sensitivity 1310nm optical transceiver, 10km,
single mode
