evertz 5700MSC-IP - System Start-Up

5700MSC-IP
IP Network Grand Master Clock & Video Master Clock System
Page - 66 Revision 0.2
9-pin Female
D-Sub
Pin
Cable
Pair
9-pin Male
D-Sub
Pin
Description
7
1
7
TX B +
2
2
TX A -
8
2
8
RX A -
3
3
RX B +
4
3
4
1 PPS +
6
6
1 PPS -
5
4
5
+12 V DC
1
1
Ground
-----------
Drain
------------
Shield
Table 4-7: Accutime Gold Extender Cable

When making your own extender cable be sure to use low capacitance twisted pair
cable and adhere to the pairing shown in Table 4-7.
4.5.3. System Start-Up
At power up, the smart antenna will automatically begin to acquire and track the GNSS satellite
signals. From a cold start, the smart antenna will normally take from 2 to 5 minutes to lock on to
sufficient satellites to accurately determine the time. During this time the Lock Status and Inputs status
screens on the front panel will show the various stages of initialization.
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
