5.4. CONFIGURING THE OUTPUTS
The OUTPUT menu is used to configure the various outputs of the 5700MSC-IP. The chart below
shows the items available in the OUTPUT menu.
SYNC 1
SYNC 2
SYNC 3
SYNC 4
SYNC 5
SYNC 6
TG 1-4 Settings
TG 1
TG 2
TG 3
TG 4
IP TG Settings
TG5, IP 1a
TG6, IP 1b
TG7, IP 1c
TG8, IP 2a
TG9, IP 2b
TG10, IP 2c
Global Pedestal
Waveform Anchor
Global Phasing
WC Lock
WC Phase
Table 5-3: Top Level of the Output Setup Menu
