With no phase offset applied, the SDI outputs of the 5700MSC-IP will be measured by
Tektronix gear as approximately 4.7us delayed (SD) or 1.3us delayed (HD) when the
Tektronix device is externally referenced to the respective analog sync
Examples of equipment that perform SMPTE compliant timing measurements are the Phabrix SX/DX
and OmniTek OTM-1000.
3.2.7. NTSC Genlock Operation
Figure 3-6: Lock Diagram #1 - NTSC Reference without 10field Reference
