5700MSC-IP
IP Network Grand Master Clock & Video Master Clock System
Revision 0.2 Page - 73
When adjusting the value of some settings, the message LIVE CONTROL will be displayed on the left
LCD with a yellow background. This message is a warning that any change made with the and
buttons or control knob will immediately be applied to the output without requiring the SELECT button
to be pressed. An example is when adjusting phase of the sync outputs or when adjusting the analog
audio levels. Proceed with caution and press the ESC button to return to the previous menu without
making a change.
5.3. CONFIGURING THE INPUT REFERENCES
The INPUT menu is used to set up various items related to the input references of the 5700MSC-IP.
The chart below shows the items available in the INPUT SETUP menu.
Frequency Ref Contains items controlling the frequency reference and how to lock to it
Time Contains items related to the time reference and how to lock to it
Jam Input
Contains live controls that can force the 5700MSC-IP to lock immediately to
the frequency or time reference
Table 5-2: Root Level of the INPUT Menu
