field pulse HD Tri-level Sync (same HD standards as sync outputs)
Number of Inputs: 2 Loop thru
High impedance, isolated, differential external termination required
Connector: 75 Ω HD-BNC, bayonet positive locking (Amphenol)
Return Loss: >40dB to 10MHz (with external 75Ω termination)
Input Level Range:
Video: -3.5dB (double-terminated) to +6dB (un-terminated)
10MHz: 0.3V p-p to 4.0V
Frequency Lock Range:
Wide mode: ±15ppm min
Narrow mode: ±0.1ppm min
2.6. SDI TEST GENERATORS (WITH +SDI-TG, OR +10G-TG OPTIONS)
Standards: With SDI-TG option SMPTE ST 259-C (270Mb/s),
With HDTG option, SMPTE ST 259-C (270Mb/s), SMPTE ST 292-1 4:2:2
With 3GTG option, SMPTE ST 259-C (270Mb/s), SMPTE 292-1 4:2:2,
SMPTE 372 dual link, and SMPTE ST 424
For SMPTE ST 2048-2 and SMPTE ST 2036-1 2160 line formats
Quad link SMPTE ST 292-1 4:2:2, Quad link SMPTE ST 424 4:2:2
SMPTE ST 425-3 Dual link 3Gb/s, SMPTE ST 425-5 Quad link 3Gb/s
Number of Outputs: 4
Embedded Audio: Up to 4 audio groups as specified in SMPTE ST 299-1 or SMPTE ST 272
Selectable tone frequencies (from 20Hz to 12kHz) and audio group
Connector: 75Ω HD-BNC, bayonet positive locking (Amphenol)
Signal Level: 800mV nominal drive
DC Offset: 0V ±0.5V
Rise and Fall Time: 100ps HD/3G, 600ps SD
Overshoot: < 10% of amplitude
Jitter: < 0.2 UI
Return Loss: > 15dB to 1.5GHz
> 10dB to 3GHz
2.7. PHYSICAL
Dimensions: 19” W x 1.75” H x 11.5” D
(483mm W x 45mm H x 292mm D)
Weight: 8lbs (3.5kg)
2.8. ELECTRICAL
Voltage: Auto ranging 100 to 240V AC, 50/60Hz
Configuration: Optional redundant supply available
Power: 125W (all options installed)
Safety: TüV Listed
Complies with EU safety directives
EMI/RFI: Complies with FCC Part 15 Class A
Complies with EU EMC Directive
