5700MSC-IP
IP Network Grand Master Clock & Video Master Clock System
Revision 0.2 Page - 21
Output
Affected by
Global Phase
Minimum Phasing
Resolution
Sync – NTSC & PAL modes
Yes
1 ns
Sync – Tri-level modes
Yes
1 ns
Sync – 5MHZ/10MHZ CW modes
No
-
Sync – NTSC/PAL subcarrier modes
No
-
Sync – PAL Color Frame Pulse
No
-
Sync – 1Hz and 1/1.001Hz Pulses
No
-
Sync – 6/1.001Hz pulse
No
-
Sync – Wordclock
Yes
59 ns
IRIG Datum Pulse
Yes
1 ms
AES/DARS outputs
(+AUX Option only)
Yes 163 ns
LTC outputs
(+AUX Option only)
Yes 1 us
SDI TG outputs
(+SDI-TG and +10G-TG Options only)
Yes
37 ns SD
13.5 ns HD & 3G
Table 3-1: Global Phasing Characteristics
