When the 5700MSC-IP is provided with a PAL reference, the AES/DARS outputs can be
deterministically phase aligned. This is because an even number of AES samples are generated
during each frame of the PAL reference. Exactly 1920 AES frames fit into a single PAL frame. The
AES/DARS/WC lck menu item should be set to PAL/integer to assure that the AES/DARS outputs are
anchored to the PAL reference. Because the AES signal coincides with the PAL signal on every frame,
the phase of the AES/DARS outputs will be the same between multiple 5700MSC-IP units that are
locked to PAL. In addition, the AES block length of 192 frames is evenly divisible into a single PAL
frame so the start of an AES block (identified by the Z preamble) will correctly align to line 1 of the PAL
reference (as illustrated in lock diagram #3 of Figure 3-9).
A PAL reference provides enough information for phasing of 50Hz and 25Hz standards, but does not
provide a long enough phase period to deterministically phase 60Hz or 24Hz standards. The
standards that can be phased properly are listed at the bottom of lock diagram #3 (Figure 3-9). The
HD standards listed apply to both the HD test generators and the tri-level sync outputs. The serial
digital video test generator outputs are phased according to SMPTE compliant timing, which may differ
from the timing shown on Tektronix equipment.
If the PAL reference is lost, the unit will freerun on the selected oscillator. Note that if the Genlock
Range is set to Wide, the freerun drift upon loss of reference will be much higher. When the PAL
reference is regained, the Lock Type menu selection controls how the 5700MSC-IP will respond to re-
align its internal oscillator with the reference.
