EVOCA Krea Touch - Page 89

04-2017 5325 00
1. water tank
2. bypass
3. water pump (alternative)
4. water inlet solenoid valve (alternative)
5. air break
6. appliance drains
7. to the appliance
8. liquid residue-draining container
9. liquid residue-collecting bucket
HYDRAULIC CIRCUIT WITH CABINET
1
2
3
4
6
5
7
8
9
9
1
3
