6 Dyvi System Components and Modularity Overview
4. Dyvi System Components and
Modularity Overview
4.1 General Description
Dyvi is a modular live production system and is scalable for any size or
type of production – from a small studio to a major live broadcasting event.
The Dyvi devices are:
• Processing Module (PM)
• Hardkey Control Panel (CP)
• Graphical User Interface (GUI)
Each of the devices works electrically independent. However, for a certain
live production multiple of these devices can be configured to contribute to
one production entity.
4.2 Processing Module (PM)
The processing Module consists of a:
• High performing COTS server
• Network interface: 100GigE
• 4 I/O boards
Figure: Dyvi Processing Module
