TECHNICAL REFERENCE MANUAL Dyvi 2.0.7.2
Processing Module Installation and Cabling 27
6.3 Processing Module Rear Panel
Description ā PMY2-5D-3216
SDI Rear Panel Overview
Figure: Processing Module Rear Panel SDI 32 IN x 16 OUT
6.3.1 Standard Backplane Interfaces
Motherboard and Power Supply Details
Power Supplies
Power Cord
Connector
Power LED
The Processing Module has two redundant power
supplies. Before booting up the system, ensure
both power supplies are fed with appropriate
supply voltage and power cords.
If power is applied, the power LED of each power
supply lights up YELLOW. If the system is turned
on, both LEDs light up GREEN.
