EVS Broadcast Equipment SA
Issue 2.0.7.2 September 2021
28 Processing Module Installation and Cabling
LAN 1 port (Dyvi
control, external
controls)
LAN 2 port
(External
controls)
IPMI port
(unused)
LAN 1 is used for connecting Dyvi control devices
and IP control of external devices and protocols.
LAN 2 is used for IP control of external devices
and protocols.
NOTE: LAN 2 does not support a Gateway.
IPMI = not used in the Dyvi application.
NOTE: Dyvi can be controlled on both ports:
• The two LAN ports must be in different
networks.
• The Full Dyvi-Native control is possible on both
LAN ports if the connection (e.g. GUI or CP) is
connected to the Main-Unit. If a connection is
established to an Extension-Unit you can
operate the menus, but you cannot handle
Production load/save operation (limited by the
GUI).
LINK-LEDs Each of the 1 GigE ports has 2 LEDs:
ACT/LINK (left side)
• OFF = No Link
• ON = Linked
• Blinking = Data Activity
Speed Link LED (right side)
• OFF = 10 Mbit
• ORANGE: 100 Mbit
• GREEN: 1 GigE
For safe Dyvi operation, the speed link LED must
light up GREEN, indicating a 1GigE speed
available.
VGA port For service purposes only.
USB ports For service purposes or connection of AUX CPs
only.
Table: List of server backplane functions relevant for Dyvi.
