TECHNICAL REFERENCE MANUAL Dyvi 2.0.7.2
Supervisor 59
10.2.3 Dyvi Cluster Settings
Overview
The Dyvi Cluster Settings are used to configure the 100 GigE streaming
cluster and environmental presets. The settings can be modified by
selecting the DYVI-Settings button in the Devices menu.
Supervisor: Dyvi Cluster Settings
Note
The video input/output standards supported for multi-PM
configurations are the following:
• 1080i50 & 1080i59
• 720p50 & 720p59
Device ID
The Device ID enumerates the Processing Modules of a cluster, starting
with Device-ID ‘1’. Device ID 1 has a special meaning in a Dyvi-
Production, since it is the Main-Processing Module which is downstream to
all the others PMs which are so called Extension Processing Modules.
Cluster ID
The Cluster ID is an identifier that enumerates independent Dyvi
Productions on the same Dyvi network.
