EVS DYVI - Control Panels and Extensions; Gui Pc

TECHNICAL REFERENCE MANUAL Dyvi 2.0.7.2
Hardware Specifications 23
5.3.2 Control Panels and Extensions
Operating
Temperature 5°C to + 35°C (32°F to 95°F) ambient with free
air flow
Relative humidity 20% to 90% (non- condensing)
Cooling requirements No active cooling at ambient temperature lower
than room temperature. Automatically controlled
forced cooling air flow from the inner panel
through a hole at the rear side of the panel.
Handling/movement Designed for fixed use when in operation
Storage and Transport
Temperature -20°C to +70°C (-4°F to 158°F)
Relative humidity 20% to 90% (non- condensing)
5.3.3 GUI PC
Operating
Temperature 0° to 35° C (32° to 95° F)
Relative humidity 20% to 80% (non-condensing at ambient)
Storage and Transport
Temperature -40° to 65° C (-40° to 149° F)
Relative humidity 5% to 95% (non-condensing at ambient)
Note
Above figures are valid for Dell OptiPlex 7480 All-in-One. Model
of GUI PC is subject to change.
