TECHNICAL REFERENCE MANUAL Dyvi 2.0.7.2
Dyvi System Components and Modularity Overview 9
4.5 Operating Interface
A Dyvi Operating Interface typically consists of:
• 1 Control Panel
• 1 Graphical User Interface
• 1 or 2 Multiviewer Screen(s) (optional & not provided by EVS), fed by
the Processing Module’s display ports.
Figure: Examples of Dyvi operating interface configuration
