EVS Broadcast Equipment SA
Issue 2.0.7.2 September 2021
20 Hardware Specifications
5.2.2 Control Panels and Extensions
Redundant Power Supply
The Control Panels are fitted with two auto switching and hot-swappable
external power supplies. The secondary hot-swappable power supply
should be connected to the mains to share the load and to allow automatic
power switching to one power supply in case one of the two should fail.
Weight
AHM100PS12: 0,5 kg (1 lb).
Dimensions
Dimensions shown in inches (mm).
Electrical Specifications
Rated voltage 100 to 240 VAC (single phase)
Rated frequency 50-60 Hz
Power supply max. 100W @100-240V
Input connector CEE 22/IEC 320 3-pin male receptacle
