EXCELL PRECISION CO., LTD
PW Service Manual SME300000016
9
1-6 Error Messages
⇒ The EEPROM is not working correctly.
⇒ Zero is higher than the zero range when switching the indicator on.
⇒ Zero is lower than the zero range when switching the indicator on.
⇒ A/D value is unstable.
⇒ A/D value is below Zero.
⇒ A/D IC malfunction (cannot read A/D value). The load cell may not be
connected to the indicator correctly.
⇒ The weight of the object is over the maximum capacity + 9 divisions.
⇒ A/D value is over the maximum range.
1-7 Weight Units
(kg) 1 g = 0.001 kg
(g) 1 g = 1 g
(lb) 1 g = 0.002204623 lb
(lb/oz) 1 g = 0.03527396 oz
(oz) 1 g = 0.03527396 oz
(GN) 1 g = 15.432358 GN
(dwt) 1 g = 0.6430149 dwt
(ct) 1 g = 5 ct
