3-5-5 Selection of the Continuous Transmission Rate
Select in the RS232 serial interface setting mode
to set the Continuous Transmission Rate.
ON/ZERO key ⇒ Increment number by 1
UNITS key ⇒ Decrement number by 1
TARE key ⇒ Move cursor one place to the right
NET/GROSS key ⇒ Move cursor one place to the left
Continuous transmission rate setting
The LCD shows the last setting.
n Default setting:
Continuous transmission rate
Use ON/ZERO or UNITS keys to select
the continuous transmission rate:
= 1 time/sec
= 2 times/sec
= 4 times/sec
= 8 times/sec
= 16 times/sec
= More than16 times/sec
ACTIONS
DISPLAY
NOTE
Press
TARE key
Use the ON/ZERO or UNITS
keys
to select the continuous
transmission
rate
Press TARE key
Key in the parameter “00”
Press the TARE key to exit
RS232 serial interface
settings
