Excell PW User Manual

EXCELL PRECISION CO., LTD
PW Service Manual SME300000016
44
3-5-1 Baud Rate Settings
Select in the RS232 serial interface setting mode
to set the Baud Rate.
ON/ZERO key ⇒ Increment number by 1
UNITS key ⇒ Decrement number by 1
TARE key ⇒ Move cursor one place to the right
NET/GROSS key ⇒ Move cursor one place to the left
Baud rate setting
LCD displays the last value
n Default value: 9600 (bits/sec)
Baud rate setting
Use ON/ZERO or UNITS keys to select the
desired Baud rate 600、1200、2400、
4800、9600、19200、38400 (bits/sec)
Press
TARE
key
Use ON/ZERO or UNITS
key
to select the desired Baud
rate
Press TARE key
Key in the parameter “00”
Press the TARE
key to exit
RS232 serial interface
settings
ACTIONS
DISPLAY
NOTE
