3-2 Advanced Function Setting Workflow
In the weighing mode, press the NET/GROSS and ON/ZERO keys at the same time to enter the
Advanced Function setting mode. The LCD shows
.
Overall workflow of the Advanced Function setting mode:
Press UNITS key
Press ON/ZERO key
Press UNITS key
Press UNITS key
Press UNITS key
Press ON/ZERO key
Press ON/ZERO key
Press ON/ZERO
key
⇒ General Function Setting Mode
⇒ External Weight Calibration
⇒ RS232 Bi-direction Function Setting
⇒ Exit the Advanced Function Setting Mode
Refer to the following sections for the detailed operation
procedures of each function setting.
