EXCELL PRECISION CO., LTD
PW Service Manual SME300000016
47
3-5-4 Continuous Transmission Settings
Select in the RS232 serial interface setting mode
to set the Continuous Transmission status.
ON/ZERO key ⇒ Increment number by 1
UNITS key ⇒ Decrement number by 1
TARE key ⇒ Move cursor one place to the right
NET/GROSS key ⇒ Move cursor one place to the left
Transmission setting
LCD shows the last setting
n Default setting:
Transmission setting
Use ON/ZERO or UNITS keys
to select the
transmission type:
= Command mode
= Continuous
transmission
= Constantly auto
transmission
= Shut down RS232
ACTIONS
DISPLAY
NOTE
Press
TARE
key
Use ON/ZERO or UNITS
keys to select the
transmission type
Press TARE key
Key in the parameter “00”
Press the TARE key to exit
RS232 serial interface
settings
