EXCELL PRECISION CO., LTD
PW Service Manual SME300000016
12
Press TARE key
Refer to “Note 3”
Press TARE key
Press TARE key
Refer to “Note 1”
Press TARE key to
complete the setting.
Input the parameter “00
kg
Refer to “Note 2”
2-1-1 Weight Units Setting
There is no resolution limitation, when the weight units “kg, g, lb, lb/oz” are selected.
The weight units ”oz, GN, dwt, and ct” are only available on indicators with less 1/10,000
external resolution.
.
.
ON/ZERO key ⇒ Increment number by 1
UNITS key ⇒ Decrement number by 1
TARE key ⇒ Move cursor one place to the right
NET/GROSS key ⇒ Move cursor one place to the left
The display shows the maximum
capacity of the scale + minimum
division and the unit weight for 2
seconds.
The display shows the maximum
capacity of the scale + minor
division size and the weight units
for 2 seconds.
Example:
Two weight units “kg” & “lb”, with
“kg” as the units used for weight
calibration.
Example:
015000 ⇒ 15.000 kg
For example:
1 ⇒ minimum division
3 ⇒ decimal point position
2 ⇒ range setting
Press TARE key
