Excell PW User Manual

EXCELL PRECISION CO., LTD
PW Service Manual SME300000016
21
Ensure the weigh pan is empty
Press the TARE key
kg
kg
Place full load (30kg in this
example) on the weigh pan
then press the
TARE key
kg
kg
Remove the weights from the
weigh
pan and press any key
to exit.
Press the TARE key to
complete weight calibration
2-2-1 Weight Calibration Setting
n For the most accurate weight calibration it is recommended that the indicator is calibrated at
full load where possible, although calibration at less than full load is also possible.
.
.
.
ON/ZERO key ⇒ Increment number by 1
UNITS key ⇒ Decrement number by 1
TARE key ⇒ Move cursor one place to the right
NET/GROSS key ⇒ Move cursor one place to the left
Press the TARE key
The display shows the calibration weight
value and the weight unit set at the first
position
4 The calibration weight value can be
changed if required
The indicator calibrates the zero point.
When the weight is stable, the display
shows the calibration weight value.
The indicator shows the weight value.
The buzzer sounds “beep, beep, beep”
when stable. Unload the weigh
pan.
When stable
Input “00”
