Setting Up Your Unit

FTB-2/FTB-2 Pro and FTB-4 Pro 139

Getting Ready to Retrieve Geolocation Information

5. If it is not done already, enable the geolocation feature:

5a. From the main window, tap .

Note: Depending on the smart device you are using, the application settings could

be found in the menu button instead.

5b. Select Settings.
