Getting Started with Your Unit

78 FTB-2/FTB-2 Pro and FTB-4 Pro

Securing your Unit Using the Kensington Lock

Your unit is equipped with a security slot to which you can connect an

optional Kensington lock (security cable) to help prevent theft.

To secure your unit:

Connect your lock to the security slot located on the left panel of your unit.
