Preparing for Automation

238 FTB-2/FTB-2 Pro and FTB-4 Pro

Changing Communication Settings

Communication settings cannot be modified without turning on your unit

and starting ToolBox X.

To change communication settings:

1. Tap the System Settings button, then tap Instrument Control

Configuration.

2. Tap Change settings, and then, when the application prompts you to

authorize the changes to your unit, tap Yes.
