Maintenance

322 FTB-2/FTB-2 Pro and FTB-4 Pro

Recycling and Disposal

3. Check and replace the fuses, if necessary.

4. Insert the new fuse into the fuse holder.

5. Make sure the fuses are placed firmly in the holder prior to reinsertion.

6. Firmly push the fuse holder into place.

Recycling and Disposal

For complete recycling/disposal information, visit the EXFO Web site at

www.exfo.com/recycle.

Fuse

Fuse holder
