Using the Optional Built-In Power Meter and VFL

166 FTB-2/FTB-2 Pro and FTB-4 Pro

To access the built-in power meter or the VFL:

From the main window, tap Power Meter and VFL.

Note: The Power Meter and VFL button is only visible if your unit is equipped

with a power meter and a VFL.

Note: You can access the online help of the power meter and the VFL by tapping

the button from the power meter application.
