Troubleshooting

352 FTB-2/FTB-2 Pro and FTB-4 Pro

Restoring Your Unit to Normal Operation

To create a WIM file for your unit:

1. On your unit, from the right side of the screen, swipe left to display the

Charm bar.

2. Tap Settings > Change PC settings.

IMPORTANT

The size of the WIM will depend on the disk space that is currently

used on your unit.

To avoid problems, always use a USB key with an NTFS file system,

and a minimum of 16 GB of free disk space.
