Data Types

392 FTB-2/FTB-2 Pro and FTB-4 Pro

Applicable Data Types for Output —IEEE 488.2

 <NR1 NUMERIC RESPONSE DATA> (or <NR1>)

This data type will be used by a device to return positive or negative

integers.

Examples: 4, –23, 90

 <NR2 NUMERIC RESPONSE DATA> (or <NR2>)

This data type will be used by a device to return positive or negative

real numbers (fixed-point numbers).

Examples: 23.45, 1.22, –4.55

<digit>
