IEEE 488.2 and Specific Command Reference

420 FTB-2/FTB-2 Pro and FTB-4 Pro

IEEE 488.2 Required Commands

*STB?

Description With the *STB? query you can read the status

byte and Master Summary Status bit. See the

content of this register below.

Syntax *STB?

Parameter(s) None

Response Syntax <RegisterValue>

N.U.

RQS/

MSS

ESB MAV N.U. EAV N.U. N.U.

MSB LSBStatus By te Register
