Test Setup - Test Configurator, Timer, and System
NetBlazer 99
Modify Structure Button
Framing: For OTN BERT, and SONET/SDH BERT test applications, the
framing is set to Framed.
OTN Multiplexing, only available with OTN BERT, indicates the OTN
test mapping.
Interface/Rate OTN Multiplexing
OTU1 [2.666 Gbit/s] ODU1
OTU2 [10.709 Gbit/s] ODU2
OTU1e [11.049 Gbit/s] ODU1e
OTU2e [11.096 Gbit/s] ODU2e
OTU1f [11.270 Gbit/s] ODU1f
OTU2f [11.318 Gbit/s] ODU2f
