Test Setup - Test Configurator, Timer, and System
108 FTB-700G/800 Series
Modify Structure Button
For Packet Sync Test Applications
 Interface/Rate: Select the desired interface rate. Choices depend on
the selected test and the rates available on the NetBlazer.
 Connector: Allows the selection of the NetBlazer’s port available for
the selected interface/rate.
Test Interface/Rate
1588 PTP
SyncE
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
a
a. The 10M rate is not available for SyncE test application.
Interface/Rate Connector
10GE LAN Port 1 - SFP+
1GE Optical
100M Optical
Port 1 - SFP
Port 2 - SFP
10/100/1000M Electrical Port 1 - RJ45
Port 2 - RJ45
