Test Setup - Test Configurator, Timer, and System
NetBlazer 109
Modify Structure Button
For Fibre Channel Test Application
 Interface/Rate: Select the desired interface rate. Choices depend on
the rates available on the NetBlazer.
 Connector: Allows the selection of the NetBlazer’s port available for
the selected interface/rate.
Interface/Rate Model
1X
2X
4X
FTB-860, FTB-860G,
FTB-720G, FTB-720G+,
FTB-730G, FTB-730G+,
FTB-870, FTB-880
8X
10X
FTB-860G,
FTB-720G+, FTB-730G+,
FTB-870, FTB-880
Interface/Rate Connector
1X
2X
4X
Port 1 - SFP
Port 2 - SFP
8X
10X
Port 1 - SFP+
