Test Setup - Test Configurator, Timer, and System
110 FTB-700G/800 Series
Modify Structure Button
For Wireless Test Application
Interface/Rate allows the selection of the interface rate.
Connector is the NetBlazer’s port available for the selected
interface/rate (see table above).
Framing
Framed L2 (default) is mainly used to validate connectivity with
the base station (REC) or remote radio head (RE) over the fiber
interface.
Unframed is mainly used to validate the continuity of the dark fiber
at CPRI or OBSAI rate.
Emulation Mode, available with Framed L2, determine the CPRI
Start-Up Sequence operation and synchronization operation.
Base Station (default) is used to validate the connectivity with the
RRH. It initiates the start-up sequence and provides
synchronization to the RRH.
Remote Radio Head is used to validate the communication with a
base station. It begins its start-up sequence when it detects a valid
signal from the base station.
Interface Rate Connector
CPRI - 1.2G
CPRI - 2.4G
CPRI - 3.1G
OBSAI - 3.1G
CPRI - 4.9G
CPRI - 6.1G
Port 1 - SFP
Port 2 - SFP
CPRI - 9.8G Port 1 - SFP+
