Test Setup - Test Configurator, Timer, and System
NetBlazer 173
MAC/IP/UDP
Modify Frame Structure
Allows to modify the structure of the frame.
 Global Option is only available with EtherSAM and Traffic Gen & Mon
test applications.
 S-OAM check box when selected, enables EtherSAM over service
OAM at Layer 2 on all services. The EtherSAM uses LBM and LBR
messages of the S-OAM protocol to perform the test. A device
having the capability to loopback LBM messages (via LBR) is
required at the remote. Only available with EtherSAM. Not available
in Dual Test Set.
 Layer Mode sets the frame layer mode for all services (available
with EtherSAM when the S-OAM check box is cleared):
Mixed (default) allows configuring the frame layer per service: L2,
L3, or L4.
L2 Only configures all services to Layer 2 only (no IP, no MPLS).
 IP Version allows to select IPv4 (default) or IPv6 that will be used
for both the interface and streams/services.
 Framing
 Frame Format (layer 2) allows to select Ethernet II (default) or
802.3 SNAP as the frame format.
 Network Layer
1, 2
(layer 3) sets the network traffic type:
IPv4 (default)/IPv6, or None.
1. Not available with EtherSAM when the S-OAM check box selected.
2. Not configurable and set to
None when Layer Mode is set to L2 Only .
