Test Setup - Test Configurator, Timer, and System
174 FTB-700G/800 Series
MAC/IP/UDP
Transport Layer
1
is disabled when the Network Layer is None.
MPLS - The MPLS Label check box, when selected (cleared by
default), enables 1 or 2 MPLS labels allowing management and test
frames to be transmitted and received. Only available with EtherSAM
and Traffic Gen & Mon test applications. Not available with EtherSAM
when the S-OAM check box selected or when Layer Mode is set to
L2 Only.
VLAN - The VLAN Tag check box when selected (cleared by default),
enables up to 3 stacked VLAN.
See VLAN on page 176 for additional VLAN settings.
Preamble/SFD
Indicates that the frame structure contains the Preamble and SFD.
1. Not available with EtherSAM when the
S-OAM
check box selected.
Test Application Transport Layer
EtherSAM None, UDP (default), TCP
RFC 2544 UDP
EtherBERT UDP (default), TCP
Traffic Gen & Mon None, UDP (default), TCP
