Test Setup - Test Configurator, Timer, and System
200 FTB-700G/800 Series
Network Details (iSAM)
Customizable Performance Criteria
As mentioned above, factory performance criteria are available and up to
25 performance criteria can be defined by editing the performance criteria
text file (iSAMPerformanceCriteriaTemplate.ini) using a word processor
application like Notepad. The file is located under
Documents and Settings\All Users\Application Data\EXFO\ProtocolProducts\.
Example of performance criteria’s text file:
Each profile entry has the following parameters:
Performance Criteria Name: 1 to 16 characters. All ASCII characters
from 32 to 126 decimal are supported.
Frame Delay (FD) Threshold: 0.015 ms to 8000 ms.
Inter-Frame Delay (IFDV) Threshold: 0.015 ms to 8000 ms.
Frame Loss Ratio (FLR) Threshold: 0% to 5%.
[MEF Metro High]
FD = 10
IFDV = 3
FLR = 0.01
[MEF Metro Med]
FD = 20
IFDV = 8
FLR = 0.01
[MEF Metro Low]
FD = 37
IFDV =
FLR = 0.1
