Test Setup - Test Configurator, Timer, and System
NetBlazer 199
Network Details (iSAM)
Each profile entry has the following parameters.
Profile Name: 1 to 16 characters. All ASCII characters from 32 to 126
decimal are supported.
Frame Type: Enter Fixed or EMIX. When the frame type is missing
from a profile, EMIX is used.
Frame Size (see Frame Size on page 195 for possible values); when
the frame size is missing from a profile, default value(s) is used:
For Fixed: Enter a unique frame size.
For EMIX: Enter 2 to 8 frame sizes with a comma between each entry.
VLAN Priority
1
(optional): Enter the priority number.
DSCP
1
(optional): Enter either the DSCP name or its binary value.
Performance Criteria
1
: Enter the name of the performance criteria.
When the Performance Criteria is missing from a profile or is not
available from the user profile file, the User Performance criteria is
used.
When a parameter is missing from a profile, the default value of the
missing parameter is used.
The value of a parameter is validated to ensure it is within the supported
range; otherwise the profile entry is unsupported.
If the profile file contain more than 25 profiles, only the first 25 valid profiles
are retained.
1. See
Classification
on page 196 for possible values.
