Test Setup - Test Configurator, Timer, and System
198 FTB-700G/800 Series
Network Details (iSAM)
Customizable Profiles
As mentioned above, 2 profiles are available by default and up to 25
profiles can be predefined by editing the profile’s text file
(iSAMProfilesTemplate.ini) using a word processor like Notepad. The file is
located under
Documents and Settings\All Users\Application Data\EXFO\ProtocolProducts\.
Example of profile’s text file:
[Priority]
Frame Type = EMIX
Frame Size = 64, 128, 512, 1024, 1518
VLAN Priority = 7
DSCP = CS7
Performance Criteria = MEF Metro High
[Best Effort]
Frame Type = EMIX
Frame Size = 64, 128, 512, 1024, 1518
VLAN Priority = 0
DSCP = CS0
Performance Criteria = MEF Metro Low
