Test Setup - Test Configurator, Timer, and System
NetBlazer 197
Network Details (iSAM)
Performance Criteria
The following performance criteria are available by default:
User Performance allows the configuration of the following values per
service:
FD (Latency): 0.015 to 8000 ms (default is 15 ms).
IFDV (Jitter): 0.015 to 8000 ms (default is 2 ms).
FLR (Frame Loss): 0 to 5% (default is 0.1%).
Note: The Performance Criteria list is user definable and up to 25 Performance
criteria can be created (see Customizable Performance Criteria on
page 200).
Name ≤ FD (ms) ≤ IFDV (ms) ≤ FLR (%)
MEF Metro High 10 3 0.01
MEF Metro Med 20 8 0.01
MEF Metro Low 37 Disabled 0.1
MEF Regional High 25 8 0.01
MEF Regional Med 75 40 0.01
MEF Regional Low 125 Disabled 0.1
MEF Continental High 77 10 0.025
MEF Continental Med 115 40 0.025
MEF Continental Low 230 Disabled 0.1
MEF Global High 230 32 0.05
MEF Global Med 250 40 0.05
MEF Global Low 390 Disabled 0.1
