Test Setup - Test Configurator, Timer, and System
NetBlazer 221
S-OAM and MPLS-TP OAM
S-OAM and MPLS-TP OAM Responder
S-OAM Responder or MPLS-TP OAM Responder check box when
selected (default) allows to respond to LBM, LTM, DMM, LMM, and SLM
valid messages (test running or not). LTM and SLM are only available with
Ethernet OAM. Traffic statistics are also monitored (refer to Responder on
page 452).
For S-OAM: A valid message must have its source MAC address matching
the Peer MEP MAC address, destination MAC address matching either the
unit port Unicast MAC address or a Multicast class 1 address, VLANs
matching the unit port VLANs, and MEG/MD Level matching the local
MEG/MD Level. Refer to Unicast/Multicast Addresses for Ethernet OAM on
page 638 for more information.
For MPLS-TP OAM: A valid message must have its: destination MAC address
matching either the unit MAC address, FF:FF:FF:FF:FF:FF, or
01:00:5E:90:00:00; VLANs matching the unit port VLANs; MPL Labels
matching the local MPLS Label Stack configuration, including GAL; MEG
Level matches the local MEG Level. For the Loopback function, a valid
message must also have its: MEP ID of the target MEP ID TLV matching the
Local MEP ID or ID Sub-Type is 0x00 (Discovery); and MEP ID and MEG ID
of the requesting MEP ID TVL, if present, matching respectively the Peer
MEP ID and the Local MEG ID.
Respond to... message Respond with... message
LBM LBR
LTM
a
a. Only available with Ethernet OAM.
LTR
DMM DMR
LMM LMR
SLM
a
SLR
