Maintenance
Pre-Maintenance
Procedures
Accessing Internal
Components
Service Interval : Y early —Apply anti-seize
compound to the cushion
knobs.
Y ou can release the cushion for rear access to the
mac hine for maintenance or adjustment.
1. Lo w er the platfor m.
2. Loosen the twist knobs on eac h side of the
mac hine .
g375719
Figure 43
1. T wist knob
2. Cushion
3. Lo w er the cushion to the platfor m.
4. R emo v e the rear access co v er .
g377627
Figure 44
5. P erfor m any maintenance or adjustment on the
mac hine .
6. Install the rear access co v er .
7. Raise the cushion, and slide it onto the pins on
both sides of the mac hine .
8. Tighten the twist knobs .
36
