Maintenance
g377041
Figure 64
Left cam shown.
1. Cam
2. Bolt
8. Adjust the cam until it aligns with the front or rear
reference bar and tighten the bolt for the cam.
Note: Mo ving the cam cloc kwise lo w ers the
handle; mo ving the cam countercloc kwise raises
the handle .
Important: Ensur e that the at por tion of
the cam does not go a bo v e a v er tical position
(right or left); otherwise y ou may dama ge the
s witch.
9. Install the rear access co v er and operator cushion.
Mower Deck Maintenance
Servicing the Cutting Blades
T o ensure a superior quality of cut, k ee p the blades
shar p . F or con v enient shar pening and re placement,
k ee p extra blades on hand.
Before Inspecting or Servicing the
Blades
1. P ark the mac hine on a lev el surface , diseng ag e
the PTO , and mo v e the motion-control lev ers
outw ard to the P ark position.
2. Shut off the mac hine , remo v e the k ey , and w ait
for all mo ving par ts to stop before lea ving the
operating position.
3. Unplug the batter y c harg er if it is connected.
4. T ur n the batter y-disconnect switc h to the Off
position.
Inspecting the Blades
Service Interval : Before each use or daily
1. Inspect the cutting edg es .
2. If the edg es are not shar p or ha v e nic ks ,
remo v e and shar pen the blade; refer to
Shar pening the Blades ( pag e 46 ) .
3. Inspect the blades , especially in the cur v ed area.
4. If y ou notice any crac ks , w ear , or a slot for ming in
this area, immediately install a new blade .
g006530
Figure 65
1. Cutting edge 3. W ear/slot forming
2. Curved area 4. Crack
45
