110

SPECIAL TOOLS LISTED BELOW FOR REMOVAL AND REINSTALLATION

NO. TOOL NUMBER

DESCRIPTION

T01

T02

T03

T04

T05

T07

T08

T09

T10

ಯTರshape of sleeve

sleeve tools᧤7mm,8mm,10mm,12mm,13mm᧥

flywheel remover

sleeve (18mm,24mm)

screw remover

cylinder pressure gauge

piston pin remover

spark plug remover

flywheel lockbolt remover

clutch clamp

཰

ཱ

ི
