16
GEAR OIL
Change as shown in the service schedule.
Inspect gear oil periodically as follows:
Remove the cover and hose
Remove the kicking starter lever
Remove clutch cover
Remove oil level bolt and inspect oil level, if oil level is below oil hole,
add oil until oil flows from the level hole.
Tighten oil level bolt to the specified torque.
Tightening toque᧶9-15N.m
᧤0.9-1.5 kg-m ᧨6.5-11.0 lb-ft᧥
BRAKES
Inspect at initially 500 km and every service, replace brake
fluid every 2 years, replace brake hose every 4 years.
Front brake fluid level
Keep the scooter upright and place the handlebar staight.
Check brake fluid level by observing the lower limit line
on the brake fluid reservoir.
When the level is below the lower limit line, replenish with
Brake fluid that meets the following specification.
Specification and classification᧶DOT4
WARNING᧶
The brake system of the scooter is filled with a glycol-based brake the lowest line
Fluid. Do not use or mix different types of fluid such as silicone-based and petroleum-based. Do not use any
brake fluid taken from old, used or unsealed containers. Never reuse the brake fluid left over from the last
servicing and stored for long periods.
