94
Reassembly and remounting
reassemble and remount the steering stem, handlebar and front
fork in the reverse order of disassembly andremoval, and also
carry out the following steps.
Install the right left suspension arms.
Steel ball
Apply grease when installing the upper and lower steel
balls.
QTY᧶upper ᧶21
lower ᧶21
Tighten the steering outer race with special tool, then extrude it 1/8-1/4round.
NOTE᧶adjustment will vary from scooter to scooter. Be sure that
the steering turns smoothly and easily, left to right.
႒ install a locknut by installing locknut and anti-dust cover
႒ screw locknut with special tool, and adjust front fork
bearing to get smooth turning.
