Front shock absorber
Adjust at initially 500km and each service.
Inspect the front shock absorber for oil leakage or other damage, and replace the defective parts, if necessary.
Rear shock absorber
Adjust at initially 500km and each service.
Inspect front shock absorber for oil leakage and other damage, and replace the defective parts if necessary.
No. Item
Nವm
Kg-m
1 Front axle nut 55-60 5.5-6
2 Handle tightenging nut 37-44 3.7-4.4
3 Steering sterm locknut 37-44 3.7-4.4
4 Disc brake caliper fixing bolt 22-29 2.2-2.9
5 Disc brake master cylinder hose fixing bolt 22-29 2.2-2.9
6 Disc brake fixing bolt 5-9 0.5-0.9
7 Front shock absorber fixing bolt 37-44 3.7-4.4
8 Engine pivot fixing nut 55-60 5.5-6
9 Engine bracket fixing nut 37-44 3.7-4.4
10 Rear wheel fixing nut 100-130 10-13
11 Rear brake rocker arm fixing bolt 5-9 0.5-0.9
12 Rear shock absorber under fixing bolt 22-29 2.2-2.9
13 Start pedal mounting screw 15-20 1.5-2
14 Rear shock absorber top fixing bolt 37-44 3.7-4.4
