ENGINE ASSY.

z Remove the muffler

z Remove cooling fan cover

z Remove cylinder cover

z Remove cooling fan

z Remove magneto nut with special tools.

z remove magneto rotor and half circle key

with special tools.

z remove magneto stator and paper gasket

z remove oil pump
