97
REMOVE
႒ Place the scooter on level ground.
႒ Remove muffler.
႒ Remove rear small fender.
႒ Remove locknut and rear wheel.
႒ Remove brake shoes.
INSPECTION
REAR RIM
Measure inner diameter of rear rim hub with micrometer, if
measured diameter exceeds 110.7, replace it with a new one.
Brake shoes
Check the brake shoe and decide whether it should be replaced or not from the thickness of the
brake shoe lining.
Service limit᧶2.5mm(0.09in)
